Dimensions (mm) | |||
---|---|---|---|
Length | Width | Height | T.Height |
256±2 | 171±2 | 201±2 | 225±2 |
![]() |
Physical Specification | ||
---|---|---|
Nominal Voltage | 12 V | |
Nominal Capacity (20 Hour Rate) | 60 Ah | |
Dimension | Lenght | 256±2 mm |
Width | 171±2 mm | |
Container Height | 201±2 mm | |
Total Height (With Terminal) | 225±2 mm | |
Weight (approximate) | 9.7 Kg | |
Acid | 1.25 g/cm3 (25˚C) | |
Acid VOL | 4.6 Liter | |
Terminal Design | T2 | |
Cell Layout | 0/1 | |
Hold Down | Not Available | |
Case | PP – Natural | |
Cover | PP – Red | |
Handle | PP – Red |
—
Terminal Design | Cell Layout | ||
---|---|---|---|
Type | ØD | ![]() |
|
Positive | Negative | ||
T2 | ![]() |
![]() |
|
![]() |
Electrical Specification | |
---|---|
Rated Capacity (20 Hour Rate @ 3.00 A) | 60 Ah |
Reserve Capacity | 89 Min. |
Cold Cranking Performance @ -18˚C (0˚F) | 290 A |
