N150 (145G51)

Automotive, Dry Charged (Conventional)
Dimensions (mm)
Length(L) Width(W) Height(H) T.Height(TH)
503±2 220±2 210±2 255±2
Physical Specification
Nominal Voltage 12 V
Nominal Capacity (20 Hour Rate) 150 Ah
Dimension Lenght 503±2 mm
Width 220±2 mm
Container Height 210±2 mm
Total Height (With Terminal) 255±2 mm
Weight (approximate) 24.5 Kg
Acid 1.25 g/cm3 (25˚C)
Acid VOL 12.0 Liter
Terminal Design T2
Cell Layout 4
Hold Down Not Available
Case PP – Natural
Cover PP – Red
Handle FIX Handle-Red

Terminal Design Cell Layout
Type ØD
Positive Negative
T2
Electrical Specification
Rated Capacity (20 Hour Rate @ 7.50 A) 150 Ah
Reserve Capacity 240 Min.
Cold Cranking Performance @ -18°C (0°F ) 685 A
