46B24L/R (NS60/L)

Maintenance Free
Dimensions (mm)
Length Width Height T.Height
235 ±2 126 ±2 201 ±2 221 ±2
Physical Specification
Nominal Voltage 12 V
Nominal Capacity (20 Hour Rate) 45 Ah
Dimension Lenght 235 ±2 mm
Width 126 ±2 mm
Container Height 201 ±2 mm
Total Height 221 ±2 mm
Weight (approximate) 12.5 Kg
Terminal Design T1
Cell Layout 0/1
Hold Down Choice of Yes/No
Case PP – Black
Cover PP – Black
Handle PP – Red
Electrical Specification
Rated Capacity (20 Hour Rate @ 2.25 A) 45 Ah
Reserve Capacity 56 Min.
Cold Cranking Performance @ -18˚C(0˚F ) 330 A
Terminal Design Cell Layout
Type ØD
Positive Negative
T1
